Concrete, steel and formwork, measured to every pour.
Concreting and reinforcement takeoffs for in-situ and precast systems, from major structural elements to small pour details, to support cost control, procurement and scheduling.
Three packages, one coordinated takeoff.
Concrete volumes, reinforcement weights and formwork areas are measured together from the same drawings, so the three packages always line up.
Concrete
In-situ and precast concrete components, from footings and slabs to small pour details.
In-situPrecastFootingsSlabsColumnsBeams- BBS where required
Reinforcement
Steel weights in kg or tonnes, broken down by bar diameter and type, with bar bending schedules where required.
By bar diameterBy bar typekg / tonnes Formwork
Formwork surface areas for every formed face, including footing sides, columns and beams.
Footing sidesColumnsBeams
Steel weights, ready to order.
Reinforcement is reported in kilograms or tonnes and broken down by bar diameter and type, so you can request supplier quotes, order accurately and avoid over-supply on site.
- Weights by bar diameter and bar type
- Mesh measured separately from loose bars
- Bar bending schedules, where required
- Ø10
- Ø12
- Ø16
- Ø20
- Ø25
- Mesh
Price it, order it, pour it on time.
Cost control
Accurate concrete, steel and formwork quantities give you a firm basis for pricing structural work.
Procurement
Order concrete, steel and formwork materials against measured quantities, not estimates.
Scheduling
Element-by-element quantities help you plan pours, crews and formwork cycles.
